Ozone Generator (Air Source) With Mixing Tower Ozone Generator (Air Source) With Mixing Tower

Quantity:
Share this:
  • Brand: KM
  • Product Description

1、the product uses the tube discharge technology, the machine has an efficient ozone mixing system, directly with the water mixed with high concentration of ozone water. Easy to install and easy to use.

2 、fully automatic intelligent control, keys can control the work of the machine, produce high concentration of ozone water, quick and safe.

3、scope of application: family water quality sanitation, small and medium-sized food processing plants, meat processing plants and small living waste water recycling treatment.

Ozone is also active in yeast and parasitic organisms, such as the ability to remove microorganisms and viruses of the following types.

The virus has proved that ozone can kill viruses very well. For example, when Poloi is 0.05-0.45mg/L, 2min will lose its activity.

Cysts under the ozone concentration of 0.3mg/L, the role of 2.4min was completely removed.

Because of the protection of spore coat, spores are 10-15 times more resistant to ozone than the growth bacteria.

Fungi albicans (Candida) and Penicillium (Penicillium) can be killed.

Parasitic organism Manson's Schistosoma mansoni (Schistosoma mansoni) was killed after 3min.

In addition, ozone can also oxidize and decompose pollutants in water, and has remarkable effect on removing odor, decoloring, sterilizing, removing phenol, cyanogen, iron, manganese and reducing COD and BOD in water treatment.

It should be noted that although ozone is a strong oxidizing agent, its oxidizing power is selective, and the readily oxidized matter, such as ethanol, is not readily associated with ozone.

Model KM-S-016-30A KM-S-016-40A KM-S-016-50A
Overall size

170*65*170cm

170*65*170cm 170*65*170cm
Tank Dia 42 * Height 155cm Dia42*Height 155cm Dia42*Height 155cm
Voltage 220V/50hz 220V/50HZ 220V/50HZ
Pump 10T/h 13T/h 16T/h
Water recycle tank 1 pc 1pc 1Opc
Electrical box 55*55*135cm 55*55*135cm 55*55*135cm
Input power 220V/50hz 220V/50HZ 220V/50HZ
Working pressure 4.5KV 4.5KV 4.5KV
Ozone capacity 30g/h 40g/h 50g/h
Ozone thickness 60mg/L-80mg/L 60mg/L—80mg/L 60mg/L—80mg/L
Whole power 2500W 2900W 3200W
Ozone capacity 30g/h 40g/h 50g/h
Ozone inhalation Jetter Jetter Jetter
Capacity 3-10T/h 3-10T/h 3-10T/h
Jetter 1 inch 1.5 inch 1.5 inch
Soda separator 1 pc 1 pc 1pc
Storage size 40*65*55cm 40*65*55cm 40*65*55cm
Frequency 800-1000hz 800-1000HZ 800-1000HZ
Rating power 780W 1100W 1200W
Type
Insert oxygen making unit Insert oxygen making unit Insert oxygen making unit
Cooling type Air cooling+water cooling Air cooling+water cooling Air cooling+water cooling

    Q:How about the spare parts?



    A:We will send one year enough easy broken spare parts together with the machines,shipping together.
    During the warranty time,we will supply the spare parts with our cost including the delivery fees.



    Q:How long time for installation?



    A:According your machines order,we will send one or two engineers to your plant,it will take about 10 days to 25 days.



    Q:How to install my machines when it arrives?how much the cost?



    A:We will send our engineers to your factory to install the machines and train your staff how to operate the machines.
    Customer pay air tickets go and back,accommodation and USD80/day/person.



    Q:When can I get my machine after I paid?



    A:Normally production time is around 30-60days,the exactly depend on what kind of machine you order.The shipping time is based on your destination port.



    Q:What’s your guarantee or the warranty of the quality if we buy your A1:machines?



    A:We offer you high quality machines with 1 year guarantee and supply life-long technical support.



    Q:Are you a trading company or a manufacturer?



    A:We are an Original Equipment Manufacturer so that we can provide you high quality machines in reasonable price, Welcome to visit us.


×
