Rotary Type Oil Filling Machine Rotary Type Oil Filling Machine

This filling machine is a high-tech filling equipment controlled by microcomputer PLC programmable,equip with photo electricity transduction and pneumatic action.

Quantity:
Share this:
  • Model: GY
  • Brand: KM
  • Product Description

1.The machine has the characteristics of compact structure, no fault control system, easy operation and high automation;

2.Contact with raw materials parts made of stainless steel, corrosion resistance, easy to clean;

3.The use of high precision and high speed quantitative filling valve, oil level accurate without loss, to ensure high quality filling;

4.The capping head is rotated continuously to ensure the quality of cover, so as not to damage the cap;

5.The use of efficient bottle cap finishing system, you can add a good cap and protection;

6.When you need to replace the bottle model, just replace the needle wheel, the bottle into the spiral and arched plate, simple and convenient operation;

7.With overload protection device, can effectively protect the safety of machines and operators;

8.Adopt a motor with adjustable speed sensor to adjust the production capacity;

9.Main electrical components, sensors, photoelectric switches, proximity switches and electrical control valves are imported components to ensure the high performance of the machine;

10.The control system has the function of automatic control of oil level, the check of bottle cap and the function of alarm and group output counting;

11.All pneumatic components using SMC.

Model: GY12-4 GY18-6 GY24-8 GY32-10
Capacity:500ml (b/h) 3000 5000 7000 10000
Bottle Applicant:(mm) 150-340 150-340 150-340 150-340
Power:(W) 2.2 3.84 3.84 5.6
Overall size L*W*H(mm) 2000*1670*2350 2070*1970*2350 2465*2170*2350 3000*2570*2350
Total Weight:(kg)
2500 3000 4000 5000
Suitable cap: Φ50-Φ110(mm)
Filling Pressure: 0.2-0.3 Mpa
Filling Temperature: Room Temperature

Q:How about the spare parts?
A:We will send one year enough easy broken spare parts together with the machines,shipping together.During the warranty time,we will supply the spare parts with our cost including the delivery fees.

Q:How long time for installation?
A:According your machines order,we will send one or two engineers to your plant,it will take about 10 days to 25 days.

Q:How to install my machines when it arrives?how much the cost?
A:We will send our engineers to your factory to install the machines and train your staff how to operate the machines.Customer pay air tickets go and back,accommodation and USD80/day/person.

Q:When can I get my machine after I paid?
A:Normally production time is around 30-60days,the exactly depend on what kind of machine you order.The shipping time is based on your destination port.

Q:What’s your guarantee or the warranty of the quality if we buy your machines?
A:We offer you high quality machines with 1 year guarantee and supply life-long technical support.

Q:Are you a trading company or a manufacturer?
A:We are an Original Equipment Manufacturer so that we can provide you high quality machines in raeasonable price, Welcome to visit us.

×
