BRIEF INTRODUCTION

OF WATER PRODUCTION LINE

Water is a multifaceted product: natural spring water, purified water, carbonated water, flavored water... What process can be used to prevent bromate formation? How to deploy mechanical filling valves to keep water crystal clear and contaminant free? How to achieve the maximum benefit with speed, accuracy and light weight bottles? King Machine, the expert in liquid product filling, will always provide you with the best solution for your products.

KEY
FEATURES

OF
WATER LINE

Water filling line can apply to fill natural spring water, purified water, carbonated water, flavored water into PET bottle by changing few spare parts.

Water filling line production capacity usual is in 1,000-36,000bph, 0.25-2.5L PET bottles are available.

Automatic water filling machine adopts Rinsing / Filling / Capping 3-in-1 technology, PLC control, touch screen, it is majnly made of SUS304/ SUS316.

Pivotal electrical parts use Mitsubishi, OMRON, and SIEMENS to water filling production line.

The whole productio filling line accuracy is more or less than 1%.

We can provide complete beverage ideal solution - blowing. filling. packing for PET bottle.

Production Line
3D Virtual Show
CAD Configuration
Water filling production line
water filling line 3D configuration
CAD configuration of water production line

For Specail Layout  Contact for Advanced Customization!

BRIEF INTRODUCTION

OF WATER FILLING PRODUCTION LINE

ModelCGF8-8-3CGF14-12-4CGF18-18-6CGF24-24-8CGF32-32-10CGF40-40-12
Capacity(500ML)2000-3000BPH3000-4000BPH6000-8000BPH8000-10000BPH12000-15000BPH16000-18000BPH
Floor area300㎡400㎡600㎡100020002500
Total power100KVA100KVA200KVA300KVA450KVA500KVA
Opertor workers886666
Watercombi-blocmachinemodelsselection
MachinemodelNo.ofblowercavityNo.offlingvalveNo.ofcappingheadCapacityBPH(1.5L/1L0.5L)
KM-CGX06-18-0661865500/8000/12000
KM-CGX08-24-0882487000/10000/16000
KM-CGX10-32-101032109000/13500/20000
KM-CGX10-40-1010401012000/18000/20000
KM-CGX12-40-1512401512000/15000/24000
KM-CGX14-45-1514451513000/20000/28000
KM-CGX16-50-1516501515000/21000/30000
KM-CGX18-60-2018602020000/24000/30000

Want to know more specifications? Click to Contact!

Layout-pet Mineral Water Production Line

This water bottling machine line is mainly used for filling drink water. It combines rinsing and filling and capping as one automatic body suitable for PET or other plastic bottles. The micro pressure filling operation of the new type is adopted enabling it to fill more efficiently and more stably with more output than the machine of the same level from others.

washing filling capping machine
  • Washing Heads

  • Filling Heads

  • Capping Heads

  • Air Conveyor

  • Flat Conveyor

WASHING HEADS

DESCRIPTION

- Into bottle way is air conveyor direct connection with bottle dial.

- All 304/316 stainless steel rinse heads, water spray style inject design, more save water consumption and more clean.

- 304/316 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing.

- 304/316 stainless steel washing pump make the machine more durable.

Washing heads of water filling machine

FILLING HEADS

DESCRIPTION

- 304/316 Stainless steel high precision filling nozzle

- Filling volume adjustable in fine rank, same liquid level after filling

- All 304/316 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean

- 304/316 stainless steel filling pump

- Efficient spray nozzle rinse thoroughly and save water for flushing

Washing heads of water filling machine

CAPPING HEADS

DESCRIPTION

- Place and capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping

- All 304/316 stainless steel construction

- No bottle no capping

- Automatic stop when lack of bottle

- Capping effect is stable and reliable, Defective rate ≤0.2%

Washing heads of water filling machine

AIR CONVEYOR

DESCRIPTION

- Air conveyor is fixed on the floor, with fan installed on the top.
- Air filter is positioned at every entrance of air fan, to prevent dust blown into bottles.
- Bottles are held on the neck in the conveyor and transported into filling machine by blowing power.
- All are made of stainless steel SUS 304 /316.
- Rack made by high quality carbon steel welded.

Washing heads of water filling machine

FLAT CONVEYOR

DESCRIPTION

- Energy saving. High efficient. Adapt to customer factory layout

- Special lubrication system, keep products clean, health, safety

- Extended service life

- Electric eyes design keep whole line running safety and quickly

- Overload protection mechanism to effectively ensure the safety of the machine

Washing heads of water filling machine

FLOW DIAGRAM

OF LAYOUT-PET MINERAL WATER PRODUCTION LINE

Water Treatment System
water treatment system
  • Raw water tank + Raw water pump

  • Silica sand filter + Active carbon filter + Sodium ion exchanger + Precision filter + Security filter

  • Reverse Osmosis (one level)

  • UV sterilizer

  • Finished water tank + Pure water pump

  • Stainless steel high pressure film shell

  • All kinds of capacity indicator, pressure indicator, electricity magnetic valve, balance device and pipe valve system

  • Online type pressure auto self-protection device

  • Online type electricity indicator (with stable compensation)

  • System safe protecting and alarm system

  • System frame

Bottle Blowing Machine Bottle Blowing Machine

Full automatic blow molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc. It is necessary for the water filling production line, 330ml-1L water filling machine line.

2

Bottle Labeling Machine

  • Heat shrink sleeve labeling machine

  • OPP Hot melt labeling machine

  • PVC label stick labeling machine

King Machine LABELLING offers a complete range of auto-matic labelling machines for glass, plastic and metal containers, for the beverage, food, household /per-sonal care, wines/spirits, chemical, pharmaceutical, and packaging industries.

1

Bottle Shrink Wrapping Machine

  • PE film shrink wrapping machine

  • Half-tray shrink wrapping machine

  • Carton box packaging machine

The range has been designed with modular units, with the large majority of structural elements shared between the different models. Common packaging methods on the market are pe film packaging and carton packaging.

More detailed equipments info  Click here
