Full Automatic CIP Cleaning System Full Automatic CIP Cleaning System

Automatic CIP system/CIP cleaning/CIP machine
Supply Ability:20 Set/Sets per Month CIP system

Quantity:
Share this:
  • Model: CIP
  • Brand: KM
  • Code: 8428909090
  • Product Description

Material:304 stainless steel,double layer,thickness of inside tank 3mm,external thickness 1.5MM,upper and bottom of tank uses conical head, diameter Ф38 for inlet and outlet. Food grade manhole, supporting feet height-adjustable, adjustable temperature meter. Dimension:1300*2200mm

Volume: 3000L*3



Concentrated acid & alkaline tank:Material:PE barrel,2pcs

Pneumatic diaphragm pump: 35L/min,2sets

Pipe filter: Φ51,SUS304、200 mesh,inlet & outlet diameterφ38

CIP process pump: 15t,SUS304、inlet&outlet diameterφ51,power:3.0KW H=24M

CIP return pumpK 20t,SUS304、inlet&outlet diameterφ51,power:4KW H=36M

Valves and pipes: Φ38, Including stainless steel valve pipeline, pneumatic bufferfly valve, magnetic valve,conner valve,T-links, elbow,quick-fitting three-piece set, square steel, etc

Auto control system: 60-90 degree, Including:8㎡ plate heat exchanger(304stainless steel)

Control system: Stainless steel box, AC contactor, Snyder electrical parts, total power: 10KW


×
