Newly designed blow dryer

Views: 705 Author: Site Editor Publish Time: Origin: Site

DB-II  (Cpaacity:8000-12000BPH)

No

Name

Quantity

Unit  Price

Total

Price

Remark

1

Stainless steel Air Knife

SS-40-350-0. 8-S1

4Pieces

4,800

4,800

1. Made of all stainless steel 304

2. Air outlet width is 0. 8mm, Adjustable range 0. 3~3mm

3. The effective length of the air outlet is 350mm

4. Single side air inlet, fit Φ51 hose (inside diameter)

2

Stainless steel Air Knife

XSS-20-70-0. 8-S1

1Piece



1. Made of all stainless steel 304

2. Air outlet width is 0. 8mm, Adjustable range 0. 3~3mm

3. The effective length of the air outlet is 70mm

4. Single side air inlet, fit Φ51 hose (inside diameter)

3

Stainless steel Air Knife

SS-40-300-0. 8-S1

2Pieces



1.Made of all stainless steel 304

2.Air outlet width is 0. 8mm, Adjustable range 0. 3~3mm

3.The effective length of the air outlet is 300mm

4.Single side air inlet, fit Φ51 hose (inside diameter)

4

High Pressure Blower

SC-5500-H3T7

1Set



1. Power 5.5KW

2. Maximum air volume 700m3/h

3. Maximum vacuum 200mbar

4. Maximum pressure 180mbar

5

High Pressure Blower

SC-2200-F1T6

1Set



1.Power 5.5KW

2.Maximum air volume 700m3/h

3.Maximum vacuum 200mbar

4.Maximum pressure 180mbar

6

Stainless steel Elbow

1piece




7

Stainless steel Filter

1piece




8

Stainless steel Coupling Joint

2pieces




9

Stainless steel Elbow

1piece




10

Stainless steel Filter

1piece




11

Φ76 Hose

6M



(Korean, PVC material)

12

Φ51 Hose

12M



(Korean, PVC material)

13

Φ25 Hose

3M



(Korean, PVC material)

14

Φ76 Hose clamp

8Pieces



(Korean, PVC material)

15

Φ51 Hose clamp

12Pieces



(Korean, PVC material)

16

Φ25 Hose clamp

3Pieces



(Korean, PVC material)

17

 Stainless steel Six-Way Joint

1Piece



Stainless steel

18

Stainless steel Tee

1Piece



Stainless steel

19

Mounting Bracket

7Sets




20

Soundproof, Waterproof Cover

1Set



1.304 stainless steel bracket + plexiglass door

2.Including exhaust fan

3.Length 1600mm * width 600mm * height 1850mm, without electric control box
