3L-10L Water Filling Machine from the washer, filling ,capping and conveyor line, linear motion and pneumatic operation, PLC control, high degree of automation is a square bottle, irregular bottle is the ideal equipment, production may be appropriate to adjust the equipment package the materials used in all high-quality stainless steel.
1.When the bottles straight from the chain of humanitarian sent to the first machine rinser; the machine in motion, in the Under the action of cam, so that folder open bottle clip and contraction of the bottle rotated 180 degrees for washing and disinfection.
2.Continue to operate, the bottle returned to the original point of view. And the open clip, under the influence of the bottle in the Jog Dial to enter delivery systems. Then transported to the filling machine parts, filling machine parts has a photoelectric detection, when the bottle is only through the Ba, the optical data into information to the PLC, PLC had instructed the cylinder block to block bottles .
3.Also, bottle filling machine rear cylinder block has also played, keep an empty bottle into the capping machine. Under the action of the program, filling the cylinder downward movement, so that within the filling valve into the bottle filling, until a certain time to stop filling, the cylinder block bottles back. Filled bottle into the capping machine, capping machine from the rack, the justifications for cover device, and even the composition of gland. Gland it is connected to the horizontal section of the dump under a certain angle, the constant movement when the bottle, put on caps. Then, the bottles with catchy article closely aligns with the gland, gland play a role.
3L-10L PET Bottle washing filling capping machine.
3L-10L PET Bottle washing machine from the washer, filling ,capping and conveyor line, linear motion and pneumatic operation, PLC control, high degree of automation is a square bottle, irregular bottle is the ideal equipment, production may be appropriate to adjust the equipment package the materials used in all high-quality stainless steel.
Containers and Specifications
Project Name:
Water / Oil / daily chemicals and something that
Automatic Linear Type 3-10L Big Bottle Filling Machine
very viscous.
Adjustable specifications of the bottle type
Material
Shape
Bottle Volume
Bottle Cap
PET / Glass / PE
Round / Square
3L-10L
Plastic Cap / Metal Cap
Accuracy
Power voltage
Control voltage
Control
±0.5%
380 V 50HZ 3phase+N+G
24 V DC/AC
PLC + Touch Screen
Packaging system
Container Label & Control Mode
Packing system
Min, Spec.
Hot Melt Roll-Fed PVC Shrink Label Full Label/ Half Label Manual / Automatic
PE Film Carton Box
1
2*3
3*4
4*6
3*5
User Ambient Conditions
Temperature：10～40℃；Humidity：No dew
User Electrical Supply Specification
Voltage：380V±5%， 3phase； Frequency：50HZ±1%
Model
XGF 4-4-1
XGF6-6-1
XGF8-8-3
Capacity
700bph 5L
1000bph 5L
1200bph 5L
Washing head
4
6
8
Filling head
4
6
8
Capping head
1
1
3
Power
2.5 kw
4.5 kw
5.5 kw
Dimension
2800mm*1100mm*1800mm
3500mm*1100mm*1800mm
4200mm*1100mm*1800mm
3L-10L WATER FILLING MACHINE
Mainly used for liquid filling, it is moderate, simple structure, easy maintenance.
